Serial interfaces - Slots A1 and A2
Notallmanufacturersusethesameconnectionconguration,sothedatalinesmay
need to be crossed
ThepotentialdifferencebetweenPGNDandthedatalinesRx-Tx,/Rx-/Tx(and
SGND)islimitedto50Vbyasuppressorcapacitor.
Forinstallationdetails,seemanual26/740“InstallationcomponentsforRS-485
networks”
