4.2.1 Installation
1)
System overview
Up to 10 sensors can be
connected in series.
These are displayed in
the system as one
sensor.
2)
Option 1:
Cut the round pin with a
knife so that the bottom
of the plastic case is flat.
3)
Option 2:
a) Stick the sensor with
the sticker on the
surface.
or
b) Secure the sensor to
the surface with the
screw.
To install extensions, switch the device off, disconnect it from the socket or at the voltage input.
