Schäfer iQdata RMS 222 User Manual

Page 24 of 86 SCHÄFER IT-Systems
Industriestraße 41  D-57518 Betzdorf
Phone: +49 (0) 2741/283-770  sales@schaefer-it-systems.de  www.schaefer-it-systems.de As
amended on 16/8/2019 (subject to technical changes)
User Manual
Article number
7808250
iQdata RMS smoke probe
Dimensions / weight
Ø diameter:
100.00 mm
Height (H):
45.00 mm
Weight:
0.29 kg
Power supply
Power supply:
via sensor cable
Connections
Sensor connection:
2x RJ12 Ports
Max. distance:
150m from the RMS system
Cascading:
Up to 10 in a row (maximum 150m length of the message chain)
Status indicators
LED indicator:
Error LED
Smoke detector spacing
Ceiling height (m)
Detection area of a
detector
Recommended distance
between detectors
Distance of a detector
from the wall
Up to 3.5m
Up to 85
9.0m
4.5m
From 3.5 to 6.0m
up to 70
8.5m
4.0m
From 6.0 to 10.0m
up to 65
8.0m
4.0m
From 10.0 to 12.0m
up to 55
7.5m
3.5m
4.3.4. Installation
To install extensions, switch the device off, disconnect it from the socket or at the voltage input.
It is essential to ensure that the smoke sensor is always installed with the sensor head down and that the
slots are not covered. In all other positions, the smoke cannot be reliably detected.
