Schäfer iQdata RMS 222 User Manual

Page 29 of 86 SCHÄFER IT-Systems
Industriestraße 41  D-57518 Betzdorf
Phone: +49 (0) 2741/283-770  sales@schaefer-it-systems.de  www.schaefer-it-systems.de As
amended on 16/8/2019 (subject to technical changes)
User Manual
5)
The sensor is installed.
4.5 Leak cable probe
Article number
7808240
iQdata RMS leak cable probe
Dimensions / weight
Width (W):
18.00 mm
Depth (D):
60.00 mm
Height (H):
18.00 mm
Weight:
75g
Inputs/ outputs
RJ11 Port
1x for connection to the RMS
Sensor for monitoring water ingress
across the area. The measurement is
carried out via a 2-wire sensor cable,
which is not included in the scope of
delivery. The connection is established via
a free sensor port and is detected
automatically by the system.
For this sensor different lengths of 2-wire
measuring cables are available.
