User Manual
The query frequency is configured in the properties of the SNMP Get element, it is currently limited and cannot be
less than 60 seconds.
11.12. Add an IP-camera
11.12.1. IP camera settings
Available settings
1
Name
The name of the element in the system
2
SNMP-Server
SNMP agent address
3
SNMP port:
SNMP agent port
4
Group
Agent read community
5
Coordination period
(sec.)
Transmission period SNMP Get in seconds (at least 60 s)
6
OID identifier
The "object identifier" in the system
7
Variable type
Object type:
 analogue - object specifies the numerical value (string or integer) that
results from a given
expression to a real number. The state of the element is specified by the
calculated value and a
predefined level is defined.
 discrete - object specifies any value (string or integer). In this case, the
expression
must contain the desired substring. If the substring is found, the state of
the element changes to
"normal", otherwise the element is in "alarm" state
8
Expression
Depending on the object type
 analogue - function of the form f (x). The standard value for the sensor is
equal to the measured value:
"x", i.e. corresponds to the expression "x". To calculate the indirect value
of the sensor, it is possible to use
any expression that is allowed "(", ")", as well as:
o operators: "+", "-", "*", "/", "%" (rest of division), "^" (exponentiation);
o Functions: "abs", "sqrt", "exp", "ln", "log", "sin", "cos", "tan", "asin",
"acos", "atan";
o Constants: "pi" (3.1415926 ...), "e" (2.718282818 ....)
For example: "0.1*x+0.5"
 discrete - any substring contained in the response in the normal state of
the object
JPEG / MJPEG
The iQdata web interface only supports IP cameras with the compression format JPEG / MJPEG video
stream.
Make sure your camera supports "MJPEG" or "JPEG".
