Page 43 of 86 SCHÄFER IT-Systems
Industriestraße 41 D-57518 Betzdorf
Phone: +49 (0) 2741/283-770 sales@schaefer-it-systems.de www.schaefer-it-systems.de As
amended on 16/8/2019 (subject to technical changes)
For all sensors except the last sensor in the chain the jumpers on 3 and 4. TR are OFF.
5.4.7. Testing the smoke sensors
While operating the system, take a needle or paper clip and insert it into the hole on the sensor cover.
Hold until the LED flashes. This means that the sensor is ready for operation.
To bring the sensor back to normal, either disconnect it from the system or select the tab Smoke
sensors restart in the Web GUI of the RMS.
5.5. pir – vibr. – temp. probe
Combination sensor for recording temperature, vibrations
as well as passive infrared motion detector for monitoring
critical areas of the company.
This sensor can monitor your rooms 24/7 for unauthorised
access or presence and provide optimal protection for your
IT.
The connection is established via a free sensor port and is
automatically detected by the system.
Freely adjustable alarm settings allow you to send specific
alarms via SNMP or e-mail, for example.
