1. The overall view of the interface is shown below:
- Menu button
- Save settings
- Quit
2. The "Menu" control panel is opened by pressing the button . It contains:
Overall Statistics - displays general statistics
Group tree - shows all sensors and devices in a folder tree (the tree is set up manually by the
administrator)
System tree - shows all sensors and devices in a system tree (the tree is automatically set up by the
system according to sensor groups)
Event log - displays the system log
Logic diagram- to define automatic actions for events in the system
Cameras - shows all cameras connected to the system
Map - developed for the visual placement of elements on the plan / map
User - to manage user accounts and permissions
CAN configuration - for controlling CAN devices
Diagrams - for a comparative analysis of the history of the sensor readings
Smoke sensor reset - resetting triggered detectors
System settings - management of the system
o Web GUI - interface language, data reload interval, activate sound for warnings
o Network - network settings
o Time - time zone, NTP server for time synchronization, current device date and time
o Syslog - Syslog server settings
o DynDNS - DynDNS service settings
o SNMP - SNMP settings
o Radius - Password storage settings
o SD card options
System menu - information about the device and software
o Info - firmware version, web GUI version, operating system, browser, system restart
o Firmware - control panel update
o Export - export sensor data, export log and export settings;
3. Overall Statistics - shows general statistics
Number of elements in the following states at the moment: very low, low, normal, warning, alarm
Condition of elements - the number of elements in the following conditions: very low, low, normal,
attention, alarm
Current log - shows the last 5 syslog events
About the system - all about the system, uptime, the browser
Time - device time, local time
