♦ Camshaft clamp - T40271-
♦ Cable support bracket - T10355-
♦ Engine bung set - VAS 6122-
♦ Sealant ⇒ Electronic parts catalogue (ETKA)
Removing
Note
♦
All cable ties must be installed in their same place again.
♦
Sealing surfaces at bottom of cylinder head cover and top of
cylinder head must not be machined.
♦
The camshaft bearings are integrated into the cylinder head
and cylinder head cover. The camshaft timing chain must be
relieved of tension before you remove the cylinder head cover.
– Remove noise insulation -1- ⇒ General body repairs - exterior
installation work; Rep. gr. 66 ; Noise insulation; Removing and
installing noise insulation .
– Remove air filter housing ⇒ page 356 .
– Remove the upper cover of the distribution chain
⇒ page 121 .
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
174 Rep. gr.15 - Cylinder head, valve gear
