Date Code 20110408 Instruction Manual SEL-551 Relay
SET.9 of 12Settings Sheets for the SEL-551 Relay
Text Settings (SET T Command)
Local Bit LB4 Name (14 characters) NLB4 =
Clear Local Bit LB4 Label (7 characters)
CLB4 =
Set Local Bit LB4 Label (7 characters)
SLB4 =
Pulse Local Bit LB4 Label (7 characters)
PLB4 =
Local Bit LB5 Name (14 characters)
NLB5 =
Clear Local Bit LB5 Label (7 characters)
CLB5 =
Set Local Bit LB5 Label (7 characters)
SLB5 =
Pulse Local Bit LB5 Label (7 characters)
PLB5 =
Local Bit LB6 Name (14 characters)
NLB6 =
Clear Local Bit LB6 Label (7 characters)
CLB6 =
Set Local Bit LB6 Label (7 characters)
SLB6 =
Pulse Local Bit LB6 Label (7 characters)
PLB6 =
Local Bit LB7 Name (14 characters)
NLB7 =
Clear Local Bit LB7 Label (7 characters)
CLB7 =
Set Local Bit LB7 Label (7 characters)
SLB7 =
Pulse Local Bit LB7 Label (7 characters)
PLB7 =
Local Bit LB8 Name (14 characters)
NLB8 =
Clear Local Bit LB8 Label (7 characters)
CLB8 =
Set Local Bit LB8 Label (7 characters)
SLB8 =
Pulse Local Bit LB8 Label (7 characters)
PLB8 =
Display Point Labels
Display if DP1 = logical 1 (16 characters) DP1_1 =
Display if DP1 = logical 0 (16 characters)
DP1_0 =
Display if DP2 = logical 1 (16 characters)
DP2_1 =
Display if DP2 = logical 0 (16 characters)
DP2_0 =
Display if DP3 = logical 1 (16 characters)
DP3_1 =
Display if DP3 = logical 0 (16 characters)
DP3_0 =
Display if DP4 = logical 1 (16 characters)
DP4_1 =
Display if DP4 = logical 0 (16 characters)
DP4_0 =
Display if DP5 = logical 1 (16 characters)
DP5_1 =
Display if DP5 = logical 0 (16 characters)
DP5_0 =
