SEON TH8 - Hardware Installation Checklist

© 2019 Safe Fleet | All rights reserved | Part #: 700-1123 R4
p. 12
TH8 Installation and Conguration Guide

Hardware Installation Checklist
√
Harnesses (camera, recorder, and accessories)
Ensure cables and harnesses are properly secured.
Check that sharp metal edges are not touching cables or harnesses.
Ensure connections are solid (no shorts).
√
Cameras
Ensure tight mounting.
Examine the internal harness connections and ensure they are solid.
Ensure the lid is properly seated on the gasket and secured tightly.
Check camera(s) eld of view.
√
DVR
Ensure tight mounting.
Check that all connections are tight.
√
System
Install fuses.
Plug portable video monitor into DVR, and power up the DVR from the vehicle ignition.
Congure the DVR to required specications locally using the mouse and monitor, or remotely
by accessing vMax Web via WiFi or Ethernet using a PC.
For more information, see "Basic DVR Conguration" on page 34.
Conrm the LAN, HDD, and PWR status indicators on the DVR front panel work properly.
Conrm that all cameras and audio sources operate properly.
Test audio/video record and playback.
Reformat the hard drives by navigating to Main Menu  Conguration  System  Program
Update  Format.
A warning message tells you all data will be erased. Click Yes. When the process completes
and a message appears, click OK. Exit the Conguration setting menu, and system setup is
complete.
Fasten and lock the front cover. Secure the cable cover on the DVR using the screws provided.
