TH8 Installation and Conguration Guide
Signals Tab - Menu Options
Menu Item Description Value [Default]
Signal Signals 1 through 5 are hardwired inputs, received through
the signal harness (LT/left turn signal - black wire, STP/
stop - green wire, BRK/brake - red wire, WRN/warning lights
- brown wire, and RT/right turn signal - white wire). When
these triggers are active, they generate signals and display
associated labels during video playback.
Signals 6 through 10 can be user-dened.
n/a
Label You can edit the on-screen display text label (maximum 3
characters) to describe each signal as desired.
For instructions on using the mouse to enter data, see "Using
On-screen Keyboards" on page 27.
Labels 1 through 5:
[LT], [STP], [BRK], [WRN], [RT].
Labels 6 through 10:
[S06], [S07], [S08], [S09], [S10]
Level Control how the signal senses activation: choose Active H
(high) if the circuit rests at 0 VDC and goes to 12 VDC when
active; choose Active L (low) if the circuit rests at 12 VDC and
drops to 0 when active.
[Active H], Active L
Alarm Select the alarm number if the signal is also used to trigger
an alarm. The alarm's input must also be set up in the Alarms
menu. For more information, see "Alarms" on page 49.
Note: assigning alarms to the default signals 1 through 5 is
generally not recommended, since these would be continually
triggered by normal vehicle operation.
[OFF], ALM1, ALM2, ALM3,
ALM4
