TH8 Installation and Conguration Guide

Alarm Settings - Menu Options
Menu Item Description Value [Default]
Alarm Click to display settings for the selected Alarm.
Alarm1 can be triggered by the optional DVR Event/Diagnostic
button through the Signals/Adaptor harness, and Alarm 2 is
triggered by the optional Alarm Button through the ALARM 2
port on the DVR rear panel. Alarms 1-4 can also be triggered
from Signals, GPS geo-fencing, G Sensor, or Excessive Speed.
[Alarm1], Alarm2, Alarm3,
Alarm4
Duration The length of time after the alarm has been triggered that
agged video is recorded at the alarm speed (FPS), quality,
and resolution settings described below.
0, 5, 10, [30] sec., 1, 3, 5, 10,
15, 20, 30, 45 min.
Input . When triggered with the
Event/Diagnostic button or the Alarm Button, use the default
setting.
Control how the alarm input senses activation: choose "N.O."
(Normally Open) or N.C. (Normally Closed).
[N.O.], N.C.
FPS For each channel, the recording speed in FPS (Frames Per
Second) used when the alarm is triggered.
If the DVR normally records at a mid-range or low FPS to
conserve storage space, set a higher FPS value to increase
video quality for a short duration to record an alarm event.
OFF, 1, 5, 7, 10, 15, 20,
[30] FPS
Quality For each channel, the recording quality used when the alarm
is triggered.
The DVR offers a range of quality settings, from 1 (low) to 4
(high).
1, 2, [3], 4
Resolution For each channel, the recording resolution (in pixels)
used when the alarm is triggered. The higher the recording
resolution, the better the picture looks, but the shorter the
recording time on a hard drive.
Three options are provided. Details depend on the camera
connected to the channel (HD 1080p, HD 720p, or Standard
Denition). The highest supported resolution is the default,
and two lower-quality options are available.
[1920 x 1080]...
[1280 x 720]...
[720 x 480]...
CH 5-8/
CH 1-4
CH 13-16/
CH 9-12
Click to work with alarms for the dened set of channels. n/a
