TH8 Installation and Conguration Guide

Adding TH4C Camera Feeds
A TH4C recorder connected to the TH8 adds support for up to 4 AHD cameras at 720p resolution.
The following TH8 cameras are not compatible with the TH4C:
HD3, CHW8, C3Q9PD, C3W9PD
NOTE: TH4C Camera Compatibility 
To enable TH4C camera feeds:
1. Connect the TH4C
• The TH4C POE-LAN port connects to an HD CAM EXPANSION port with a CAT5e cable (see "DVR Back
Panel Features" on page 21).
2. Congure the TH4C
• Set the NetworkSettings  Setting Type to DHCP (for more information, see the
).
• If Record-Off Delay Time or Power-Off Delay Time are used, congure these settings on the TH4C to
match the TH8. For more information, see "Recording Settings" on page 52.
TIP: Set FPS, Quality, and Resolution on the TH4C 
TH4C camera feeds are sent to the TH8 as RTSP stream pairs, so the video sources are not
congurable on the TH8. If you need to change FPS, Quality, or Resolution settings, they must be
congured on the TH4C.
3. Congure the TH8 for the TH4C
• Select TH4C in the Record  HD Cam Expansion 1 or HD Cam Expansion 2 menu, depending on the
expansion port used (see "IP Cameras and RTSP Video Sources" on page 52).
• Enter a name and logical channel (display location) for each TH4C RTSP stream (for more
information, see "To congure streams from a companion DVR (e.g.TH series):" on page 45).
Adding an IP Camera
1. Connect the camera
• Use an HD CAM EXPANSION port (see "DVR Back Panel Features" on page 21).
2. Congure the Expansion port
• Select IP in the Record  HD Cam Expansion 1 or HD Cam Expansion 2 menu, depending on the
expansion port used (see "IP Cameras and RTSP Video Sources" on page 52).
3. Congure the camera
• Make selections in Record  Camera  IPC 1 or IPC2 tab, depending on the expansion port used (see
"To congure a supported IP camera:" on page 43).
