TH8 Installation and Conguration Guide
Installing the DVR
Tools and Equipment
The DVR system must be installed by a professional installer. A professional installer has the experience and
equipment to install and congure this DVR system to run properly.
Check that you have all the system components and inspect the units for any scratches or damage before
installing.
Keys (included in package contents):
• DVR keys for securing the removable hard drive
• Front cover keys for securing the removable front cover
Conguration equipment:
• Local on-screen conguration requires a portable video monitor and a mouse (contact Customer
Service for more information)
• Conguration from a browser (vMax Web) requires a laptop and an Ethernet cable
Physical Location
The DVR is secured with a security front cover and a cable cover. The cable cover allows wiring to enter from
the underside of the back of the unit.
The DVR is designed for horizontal installation, on top of the mounting plate (see the diagram on page 8),
but may be installed vertically if required. Do NOT install the DVR upside down.
WARNING: Risk of Heat or Moisture Damage
Do not install the DVR in a location where the unit is exposed to excessive heat or moisture.
Installation close to extreme heat or moisture voids the product warranty.
Route wiring and cables away from sharp edges that might damage the insulation. Avoid sharp bends in
the cable.
Contact Technical Support before attaching the DVR to other equipment in the vehicle.
Before installing the DVR, keep in mind that a well-ventilated location and sufcient clearance around the unit
are key factors for performance and maintainability. The following table provides information on installation
requirements.
To Next Page
