© 2019 Safe Fleet | All rights reserved | Part #: 700-1123 R4
p. 53
TH8 Installation and Conguration Guide
Recording Settings - Menu Options
Menu Item Description Value [Default]
Repeat
Record
Leave this setting at the default [ON] for the storage media to loop,
and record over the oldest video when it becomes full (the "HD Used"
metadata item displays "Repeating" - for more information see "Metadata
Details" on page 41).
When set to OFF, the DVR stops recording when storage is full ("HD Used"
displays 100%).
[ON], OFF
Record-On
Delay Time
Leave at default to let the voltage settle after the vehicle starts up to
prevent voltage drops affecting the DVR.
Enables a time delay after the vehicle ignition is turned on until the DVR
starts.
[15 sec.], 30 sec.,
1 min., 5 min.,
10 min., 20 min.,
30 min.
Record-Off
Delay Time
To keep the DVR and cameras on after the ignition turns off (e.g. to
record the post-trip check), set this to 10 or 20 min.
Enables a time delay to continue recording after the ignition signal to the
DVR is turned off. The power output connector on the DVR rear panel
remains active during this time.
[15 sec.], 30 sec.,
1 min., 5 min.,
10 min., 20 min.,
30 min.
Power-Off
Delay Time
If the system is not using Wi-Fi, use the default setting. If Wi-Fi is used,
set to 2 hours or more. For more information, see the Commander User
Guide on the Safe Fleet Community.
This sets the time delay from the record delay until power is shut off.
The delay begins after "Record Delay Off" time ends. During this time,
cameras are turned off and recording is stopped. However, the control
connector on the DVR rear panel remains active to allow peripherals such
as Smart-Reach to be powered up during the power delay time.
[15 sec.], 0 sec.,
30 sec., 1 min.,
5 min., 10 min.,
20 min., 30 min.,
45 min., 1 hr., 2 hr.,
4 hr.
Enable Dual
Drive
Leave at the default setting unless the DVR has 2 drives installed.
When 2 drives are installed, enable this setting to ensure accurate hard
drive status reporting.
[OFF], ON
Record2 Leave at the default setting unless instructed otherwise.
Unless set to OFF, the DVR records a low resolution second video stream
at the selected frame rate. The DVR can record video in two streams:
one at high resolution for full, detailed event information, and the other
(Record2) at lower resolution for fast downloading or real-time viewing
over a low bandwidth network such as a cellular link. In the event of
an emergency, if the system is congured with Smart-Reach cellular
hardware and a cellular plan, Record2 allows quick access to video
online. Use the Record2 setting to specify a lower per second recording
(frame rate) for the second video stream.
[5 fps], OFF, 1 fps,
2 fps, 3 fps, 4 fps,
5 fps
