TH8 Installation and Conguration Guide

Monitor Settings - Menu Options
Menu Item Description Value [Default]
Front
Default
Display
Select the default monitor display setting: all cameras (9 UP) or a single
camera (choose the Channel/Camera Name it is connected to).
[9 UP], Channel
01...
Display
Switch
Enable or disable switched display.
Select ON if you want to switch the monitor display from the default
setting to another camera feed based on an Alarm, a Signal, or a
specied time, as per the options detailed below (these parameters are
unavailable when Display Switch is OFF).
[OFF], ON
Switch To When Display Switch is ON, select the camera feed to activate based on
the Alarm, Signal, or Timer setting described below.
You can choose to display a single camera (by Channel number), all
connected cameras (9 UP), or to show each active camera feed in
sequence (Sequence - applies only to the Timer option described below).
Channel 01...,
[9UP], Sequence
Switch On Set the trigger type that will activate the camera feed selected in the
Switch To setting and cause it to display in the monitor output.
Then, from the pull-down menu below, select a specic Alarm, Signal, or
Timer setting.
Alarm, [Signal],
Timer
Alarm
(Signal or
Timer)
For Alarm or Signal trigger types: choose the specic Alarm/Signal to
activate the selected camera view in the monitor output display when
Display Switch is ON. For example, the ALM1 setting switches monitor
output to the view selected in the Switch To option for the duration of
ALM1.
For the Timer trigger type: select the amount of time each active video
channel displays during rotation. For example, 10sec changes channels
between valid camera inputs every 10 seconds.
[ALM 1]...
[Signal 1]...
[3 sec.], 5 sec, 10
sec. 30 sec.
