TH8 Installation and Conguration Guide
Wake on Input, Digital Output - Menu Options
Menu Item Description Value [Default]
Wake on
Input
Select the input action that wakes up the DVR:
OFF: the DVR ignores the Wake on Input signal.
TEMP PWR: the DVR wakes into temporary power mode (boots up and
stays powered for 5 minutes).
ALM1: DVR powers on and enters Alarm 1 mode (as per the congured
Alarm 1 duration and recording settings).
For more information see "Alarms" on page 49.
[OFF], ALM1, TEMP
PWR
Digital
Output
(Active)
Select the type of system events which, if detected, generate a DVR
output signal to an external device through the Expansion port.
Alarms: the DVR generates an output whenever an alarm is detected.
Video Loss: the DVR generates an output whenever an video loss event
is detected.
[OFF], Alarms,
Video Loss
Digital
Output
(Output)
Select the type of signal generated when Digital Output is triggered:
Active H: the Digital Output circuit rests at ground and goes to 12 VDC
(150 mA source) when active.
Active L: circuit rests at 12 VDC and drops to ground (350mA sink) when
active.
[Active H], Active L
