Sharp MX-2300 G

MX-2300/2700 N/G SIMULATION 7 – 10
2-2
Purpose : Operation test/check
Function (Purpose) : Used to check the operations of the sen-
sors and detectors in the automatic docu-
ment feeder unit and the related circuits.
Section :RSPF
Item : Operation
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The active sensors and detectors are highlighted.
NOTE: SWD_LEN and SWD_AD are not ON/OFF display.
2-3
Purpose : Operation test/check
Function (Purpose) : Used to check the operations of the loads
in the automatic document feeder unit and
the control circuits.
Section :RSPF
Item : Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The selected load operation is performed.
When [EXECUTE] button is pressed, the operation is termi-
nated.
*1: Since the stamp solenoid is an option unit, it can be operated
only when it is installed.
* For the same loads displayed separately depending on normal
rotation and rotation, if they are selected together, normal rota-
tion is performed.
In addition, if the load is rotating, reverse rotation is not accepted
until the operation is stopped.
3
3-2
Purpose : Operation test/check
Function (Purpose) : Used to check the operation of sensor and
detector in the finisher and the related cir-
cuit.
Section : Finisher
Item : Operation
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The active sensors and detectors are highlighted.
<Saddle finisher>
Button
display
Content
Selectable
magnification ratio
Default
value
50 Scan magnification ratio:
50%
COLOR: 50%, 100%,
200%
BLACK (High speed):
100%, 200%
BLACK (Low speed):
50%, 100%, 200%
100%
100 Scan magnification ratio:
100%
200 Scan magnification ratio:
200%
SSET SPF installation detection
SOCD SPF open/close detection
SCOV SPF cover SW
SPED SPF document empty detection
SPPD1 SPF paper entry detection 1 and random detection
(common)
SPPD2 SPF paper entry detection 2 PS front
SPPD3 SPF before-scan detection
SPPD4 SPF Reverse gate front detection
SPPD5 SPF Reverse rear detection
SPLS1 SPF Document length detection short
SPLS2 SPF Document length detection long
STMPU SPF stamp unit installation detection
SWD_LEN SPF guide plate position
SWD_AD SPF document detection volume output
CLOSE
BLACK(SLOW)
0
SIMULATION NO.02-01
RSPF AGING
TEST
EXECUTE
150 200
ZOOM
100
%
BLACK(FAST) COLOR
2-SIDE
1-SIDE
25
50
100
300
400
0
RSPF SENSOR CHECK SWD_LEN: **** SWD_AD: ***
1/1
CLOSE
SIMULATION NO.02-02
TEST
1/1
SSET
SOCD
SCOV
SPED
SPPD1 SPPD2
SPPD3
SPPD4
SPPD5
SPLS1 SPLS2
STMPU
SPFM SPF transport motor
SPRM_F SPF paper feed reverse motor normal rotation
SPRM_R SPF paper feed reverse motor reverse rotation
SPFC SPF paper feed clutch
SRRC SPF resist roller clutch
SGS SPF document exit gate solenoid
STMPS Finish stamp solenoid (*1)
FJPID Interface transport unit entry port detection
FJPOD Interface transport unit exit port detection
FJPDD Interface transport unit cover detection
FED Entry port paper detection
FPDHPD Paddle HP detection
FARHPD Bundle roller HP detection
FFJHPD Alignment plate HP detection front
FRJHPD Alignment plate HP detection rear
FAD Alignment tray detection
FOBHPD Discharge belt HP detection
FBED Tray paper detection
FSLD Paper surface detection
FFPD Binding position detection
FFHPD Binding HP detection
FFRHPD Binding roller HP detection
FFED Binding paper detection
FFE Binding lock detection
FULD Lift upper limit detection
FLLD Lift lower limit detection
㩷
㩷
㩷
㩷
㩷
㩷
㩷
SIMULATION  NO.02  03
TEST
RSPF OUTPUT CHECK
 SPFM
SPRM_F
SPRM_R
SPFC
SRRC
SGS
1/1
EXECUTE
0
 STMPS
CLOSE
