MX-2300/2700 N/G SIMULATION 7 – 11
<Saddle finisher punch unit>
<Inner finisher>
<Inner finisher punch unit>
3-3
Purpose : Operation test/check
Function (Purpose) : Used to check the operation of the load in
the finisher and the control circuit.
Section : Finisher
Item : Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The selected load operation is performed.
When [EXECUTE] button is pressed, the operation is termi-
nated.
<When the saddle finisher is installed>
<When the inner finisher is installed>
<External punch unit>
<Inner punch unit>
FLE Lift lock detection
FSHPD Staple drive HP detection
FSTHPD Staple shift HP detection
FSD Staple empty detection
FSUC Staple connection detection
FSPD Self prime detection
FMLD Tray intermediate detection
FFDD Front door detection
FCD Upper cover detection
FFDSW Front door SW detection
FJSW Joint SW detection
FSSSW Staple safety SW detection
FFANLK Fan motor lock detection
FPE Punch motor lock detection
FPUC Punch unit connection detection
FPHPD Punch HP detection
FPDD Punch dust detection
FPSHPD Punch horizontal resist HP detection
FPTD Punch timing detection
FPSD1 Punch horizontal resist detection 1
FPSD2 Punch horizontal resist detection 2
FPSD3 Punch horizontal resist detection 3
FPSD4 Punch horizontal resist detection 4
FED Entry port paper detection
FBED Tray paper detection
FULD Tray upper limit detection
FMLLD Tray intermediate lower limit detection
FLLD Tray lower limit detection
FSLD1 Paper surface detection 1
FSLD2 Paper surface detection 2
FRLD Roller up/down detection
FBRD Belt separation detection
FFJHPD Alignment plate HP detection front
FRJHPD Alignment plate HP detection rear
FJPD Alignment guide position detection
FSTPD Staple tray paper detection
FSHPD Staple drive HP detection
FSTHPD Staple shift HP detection
FSD Staple empty detection
FSTD Staple lead edge position detection
FDSW Door open detection
FFANLK Fan motor lock detection
FPRPD Punch rear position detection
FPUC Punch unit connection detection
FPHPD Punch HP detection
FPSHPD Punch horizontal resist HP detection
FPDD Punch dust detection
FPPEND Punch paper rear edge detection
FPPD1 Punch paper surface detection 1
FPPD2 Punch paper surface detection 2
FPPD3 Punch paper surface detection 3
FPPD4 Punch paper surface detection 4
FPPD5 Punch paper surface detection 5
FPPD6 Punch paper surface detection 6
FPDES1 Punch destination detection 1
FPDES2 Punch destination detection 2
FINRPS Entry port reverse solenoid
FJPM Interface transport motor
FJFM Interface transport fan motor
FFM Transport motor
FPM Paddle motor
FAM Bundle paper exit motor
FFJM Alignment motor front
FRJM Alignment motor rear
FSM Staple shift motor
FFSM Staple motor
FLM Lift motor
FFC Folding clutch
FINRPS Entry port reverse path solenoid
FSLS Paper surface detection solenoid
FPDS Paddle solenoid
FBRS Belt separation solenoid
FRM Resist motor
FSWM Oscillation motor
FAM Bundle paper exit motor
FFJM Alignment motor front
FRJM Alignment motor rear
FSM Staple shift motor
FFSM Staple motor
FTLM Tray lift motor
FFANM Fan motor
FPNM Punch motor
FPSM Punch horizontal resist motor
FPNM Punch motor
FPSM Punch horizontal resist motor
0
FIN SENSOR CHECK
CLOSE
SIMULATION NO.03-02
TEST
1/2
FJPID FJPOD FJPDD FED
FPDHPD FARHPD FFJHPD FRJHPD
FAD FOBHPD FBED FSLD
FFPD FFHPD FFRHPD FFED
FFE FULD FLLD FLE
