Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the RSPF misfeed positions
and the number of misfeed at each posi-
tion. (When the number of misfeed is con-
siderably great, it can be judged as
necessary for repair.)
Section :RSPF
Item : Function
Operation/Procedure
The history of paper jam and misfeed is displayed.
The misfeed history is displayed sequentially from the latest one.
The max. 50 items are recorded. (The oldest one is sequentially
deleted.) This data can be used to identify the trouble position.
Press [COLOR] or [BLACK] button to print.
List of JAM codes: Refer to "2. Paper JAM code" in the "[12] OTH-
ERS".
22-13
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the operating time of the
process section (OPC drum, DV unit, toner
cartridge).
Section :—
Item : Counter
Operation/Procedure
The rotating time and the print quantity of the process section are
displayed.
Change the display with [↑] [↓] buttons.
Press [COLOR] or [BLACK] button to print.
22-19
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the values of the counters
related to the scan mode and the internet
FAX mode.
Section : Scanner
Item : Counter
Operation/Procedure
Used to display the counter value related to the network scanner.
Change the display with [↑] [↓] buttons.
Press [COLOR] or [BLACK] button to print.
DRUM CTRG K Drum cartridge print counter (K)
DRUM CTRG C Drum cartridge print counter (C)
DRUM CTRG M Drum cartridge print counter (M)
DRUM CTRG Y Drum cartridge print counter (Y)
DRUM RANGE K Drum cartridge accumulated traveling distance
(CM)(K)
DRUM RANGE C Drum cartridge accumulated traveling distance
(CM)(C)
DRUM RANGE M Drum cartridge accumulated traveling distance
(CM)(M)
DRUM RANGE Y Drum cartridge accumulated traveling distance
(CM)(Y)
DEVE CTRG K Developer cartridge print counter (K)
DEVE CTRG C Developer cartridge print counter (C)
DEVE CTRG M Developer cartridge print counter (M)
DEVE CTRG Y Developer cartridge print counter (Y)
DEVE RANGE K Developer cartridge accumulated traveling distance
(CM)(K)
DEVE RANGE C Developer cartridge accumulated traveling distance
(CM)(C)
DEVE RANGE M Developer cartridge accumulated traveling distance
(CM)(M)
DEVE RANGE Y Developer cartridge accumulated traveling distance
(CM)(Y)
TONER MOTOR K Toner motor print counter (K)
TONER MOTOR C Toner motor print counter (C)
CLOSE
SIMULATION  NO.22 㧙 12
52(,#/*+5614;&#6#&+52.#;
TEST
CLOSE
0





















TONER MOTOR M Toner motor print counter (M)
TONER MOTOR Y Toner motor print counter (Y)
TONER TURN K Toner motor accumulated rotation time (SEC)(K)
TONER TURN C Toner motor accumulated rotation time (SEC)(C)
TONER TURN M Toner motor accumulated rotation time (SEC)(M)
TONER TURN Y Toner motor accumulated rotation time (SEC)(Y)
NET SCN ORG_B/W Network scanner document read quantity
counter (B/W) (B/W scan job)
NET SCN ORG_CL Network scanner document read quantity
counter (COLOR) (Color scan job)
NET SCN ORG_2CL Network scanner document read quantity
counter (2-COLOR) (2-Color scan job)
NET SCN ORG_SGL Network scanner document read quantity
counter (SINGLE) (Single-color scan job)
INTERNET FAX OUTPUT Number of times of internet FAX output
INTERNET FAX SEND
OUTPUT
Number of times of internet FAX send
INTERNET FAX RECEIVE Number of times of internet FAX receive
INTERNET FAX SEND Number of times of internet FAX send
MAIL COUNTER Number of times of E-MAIL send
FTP COUNTER Number of times of FTP send
SMB SEND Number of times of SMB send
USB CNT Number of times of USB storage
TRIAL MODE_B & C Trial mode counter (B/W & COLOR scan
job)
SCAN TO HDD_B/W SCAN TO HDD record quantity (B/W)
SCAN TO HDD_CL SCAN TO HDD record quantity (COLOR)
SCAN TO HDD_2CL SCAN TO HDD record quantity (2-COLOR)
SCAN TO HDD_SGL SCAN TO HDD record quantity (SINGLE
color)
DRUM CTRG K
SIMULATION  NO.22  13
TEST
PROCESS CARTRIDGE DISPLAY
CLOSE
00000000
: DRUM RAN G E K
00000000
:
DRUM C TRG C
 00000000
:
DRUM RAN G E C
00000000
:
DRUM C TRG M
 00000000
:
DRUM RAN G E M
00000000
:
DRUM C TRG Y
 00000000
: DRUM RAN G E Y
00000000
:

1/2
0
NET SCN ORG_2CL
 00000000
:
SIMULATION  NO.22  19
TEST
NETWORK SCANNER COUNTER DISPLAY
CLOSE
1/4
NET SCN ORG_B/W
 00000000
:
NET SCN ORG_CL
 00000000
:
NET SCN ORG_SGL
 00000000
:
INTERNET FAX OUTPUT
 00000000
:
