MX-2300/2700 N/G SIMULATION 7 – 22
22-9
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the number of use (print
quantity) of each paper feed section.
Section : Paper feed, ADU, LCC
Item : Counter
Operation/Procedure
The values of the paper feed related counters are displayed.
Press [COLOR] or [BLACK] button to print.
22-10
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the system configuration
(option, internal hardware).
Section :—
Item : Specifications (Option)
Operation/Procedure
1) The system configuration is displayed. (The model names of
the installed devices and options are displayed.)
2) Change the display with [↑] [↓] buttons.
Press [COLOR] or [BLACK] button to print.
22-11
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the use frequency (send/
receive) of FAX. (Only when FAX is
installed)
Section :FAX
Item : Counter
Operation/Procedure
The values of the FAX send counter and the FAX receive counter
are displayed.
Press [COLOR] or [BLACK] button to print.
TRAY1 Tray 1 paper feed counter
TRAY2 Tray 2 paper feed counter
TRAY3 Tray 3 paper feed counter
TRAY4 Tray 4 paper feed counter
MFT TOTAL Manual paper feed counter (Total)
MFT HEAVY Manual paper feed counter (Heavy paper)
MFT OHP Manual paper feed counter (OHP)
MFT ENV Manual paper feed counter (Envelope)
LCC Side LCC paper feed counter (A4LCC)
ADU ADU paper feed counter
Item display Display content Content
MACHINE MX-2300G Machine
MX-2300FG
MX-2700G
MX-2700FG
MX-2300N
MX-2700N
RSPF/DSPF MX-RPX1/
STANDARD
Document feed unit
STAMP AR-SU1 Finisher stamp
DESK MX-DEX1 Desk unit
MX-DEX2
LCC MX-LCX1 Large capacity cassette (Side LCC)
RSPF/DSPF : 00000000
SCAN : 00000000
STAPLER : 00000000
PUNCHER : 00000000
STAMP : 00000000
SIMULATION NO.22-08
TEST
ORG./STAPLE COUNTER DISPLAY
CLOSE
SADDLE STAPLER : 00000000
OC OPEN : 00000000
RSPF/DSPF_OPEN : 00000000
OC LAMP TIME : 00000:00
0
TRAY1 : 00000000
TRAY2 : 00000000
TRAY3 : 00000000
TRAY4 : 00000000
MFT TOTAL : 00000000
SIMULATION NO.22-09
TEST
PAPER FEED COUNTER DISPLAY
CLOSE
MFT HEAVY : 00000000
MFT OHP : 00000000
MFT ENV : 00000000
LCC : 00000000
ADU : 00000000
1/1
0
PUNCHER MX-PNX1A Punch unit
MX-PNX1B
AR-PN1A
AR-PN1B
FINISHER MX-FNX1 Finisher
MX-FNX2
FAX1 MX-FXX1 FAX kit
FAX2 MX-FLX1 FAX2 line kit
FAX MEMORY AR-MM9 FAX expansion memory
MX-MMX1
HAND SET MX-HNX1 Handset
NETWORK
SCANNER
MX-NSX1 Network scanner expansion kit
PRINTER MX-PBX1 Printer expansion kit
PS MX-PKX1 PS expansion kit
SECURITY MX-FRX1 Security kit
AIM MX-AMX1 Application expansion kit
SDRAM(SYS) *****MB SDRAM capacity
SDRAM(ICU) *****MB SDRAM capacity
HDD *****MB Hard disk capacity
NIC STANDARD NIC
BARCODE AR-PF1 Barcode font
INTERNET-FAX MX-FWX1 Internet Fax expansion kit
FAX OUTPUT FAX print quantity counter (for line 1)
FAX OUTPUT_L2 FAX print quantity counter (for line 2)
FAX SEND FAX send counter
FAX RECEIVED FAX receive counter
SEND IMAGES FAX send quantity counter (for line 1)
SEND IMAGES_L2 FAX send quantity counter (for line 2)
SEND TIME FAX send time
RECEIVED TIME FAX receive time
ACR SEND Number of carrier prefix adding communications
Item display Display content Content
SIMULATION NO.22-10
MACHINE SYSTEM
TEST
CLOSE
0
MACHINE
:
MX-2300G
RSPF/DSPF
:
MX-RPX1/STANDARD
STAMP
:
AR-SU1
DESK
:
MX-DEX1
LCC
:
MX-LCX1
PUNCHER
:
MX-PNX1A
FINISHER
:
MX-FNX1
FA X 䋱
:
MX-FNX1
1/ 3
FA X 2
:
MX-FLX1
FA X M E MO RY
:
AR-MM9
FAX OU T PU T
SI MU LATI O N
NO.22
11
TEST
FAX COUNTER DISPLAY
CLOSE
00000000
㧦 SEND IMAGES_L2
00000000
㧦
FAX OU TPU T_L2
00000000
㧦
SEND TIME
00000000:00:00
㧦
FAX SEND
00000000
㧦
RECEIVED TIME
00000000:00:00
㧦
FAX RECEIVED
00000000
㧦
CR SEND
㧦
SEND IMAGES
00000000
㧦
1/1
0
00000000
