MX-2300/2700 N/G SIMULATION 7 – 28
25
25-1
Purpose : Operation test/Check
Function (Purpose) : Used to check the operations of the devel-
oping section.
Section : Process (Developing section)
Item : Operation
Operation/Procedure
1) Select the process speed with [MIDDLE] and [LOW] buttons.
2) Press [EXECUTE] button.
The developing motor and the OPC drum motor rotate for 3
min and the detection level of the toner density sensor is dis-
played.
25-2
Purpose : Setting
Function (Purpose) : Used to make the initial setting of toner
concentration when replacing developer.
Section : Process (Photoconductor/Developing/
Transfer/Cleaning)
Item : Adjustment
Operation/Procedure
1) Select the adjustment target with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The toner concentration sensor makes sampling of toner con-
centration to display the detection level.
NOTE: When the above operation is interrupted on the way, the
reference toner concentration level is not set. Also when
error code of EE-EC, EE-EL or EE-EU is displayed, the ref-
erence toner concentration level is not set normally.
26
26-1
Purpose :Setting
Function (Purpose) : Used to set the paper exit tray (MX-TRX1).
Section : Paper exit
Item :Setting
Operation/Procedure
1) Enter the set value with 10-key.
2) Press [OK] button to save the entered content in step 1).
TCD_K Toner concentration sensor K
TCD_C Toner concentration sensor C
TCD_M Toner concentration sensor M
TCD_Y Toner concentration sensor Y
TCV_K Toner concentration control voltage K
TCV_C Toner concentration control voltage C
TCV_M Toner concentration control voltage M
TCV_Y Toner concentration control voltage Y
Display items Item descriptions
Display
range
Default
value
AT DEVE ADJ_L_K Automatic developer
adjustment value at low
speed
1 – 255 128
AT DEVE ADJ_L_C 1 – 255 128
AT DEVE ADJ_L_M 1 – 255 128
AT DEVE ADJ_L_Y 1 – 255 128
AT DEVE ADJ_M_K Automatic developer
adjustment value at middle
speed
1 – 255 128
AT DEVE ADJ_M_C 1 – 255 128
AT DEVE ADJ_M_M 1 – 255 128
AT DEVE ADJ_M_Y 1 – 255 128
LOW
MIDDLE
0
SIMULATION
NO.25-01
TEST
TONER SENSOR OUTPUT MONITOR
TCD_㧷
:
TCV_㧷
:
TCD_C
:
TCV_C
:
TCD_M
:
TCV_M
:
TCD_Y
:
TCV_㨅
:
1/1
CLOSE
AT DEVE VO_L_K Automatic developer
adjustment control voltage
at low speed
1 – 255 128
AT DEVE VO_L_C 1 – 255 128
AT DEVE VO_L_M 1 – 255 128
AT DEVE VO_L_Y 1 – 255 128
AT DEVE VO_M_K Automatic developer
adjustment control voltage
at middle speed
1 – 255 128
AT DEVE VO_M_C 1 – 255 128
AT DEVE VO_M_M 1 – 255 128
AT DEVE VO_M_Y 1 – 255 128
TCD_K Toner concentration sensor K
TCD_C Toner concentration sensor C
TCD_M Toner concentration sensor M
TCD_Y Toner concentration sensor Y
TCV_K Toner concentration control K
TCV_C Toner concentration control C
TCV_M Toner concentration control M
TCV_Y Toner concentration control Y
Item Display Content
Set
range
Default
A (0:YES 1:NO) 0 Escape tray YES 0 to 1 1 (NO)
1 Escape tray NO
Display items Item descriptions
Display
range
Default
value
0
SIMULATION
NO.25-02
TEST
AUTOMATIC DEVELOPER ADJUSTMENT
EXECUTE
AT DEVE ADJ_L_K
128
:
AT DEVE VO_L_K
128
:
AT DEVE ADJ_L_C
128
:
AT DEVE VO_L_C
128
:
AT DEVE ADJ_L_M
128
:
AT DEVE VO_L_M
128
:
AT DEVE ADJ_L_Y
128
:
128
:
1/2
CLOSE
AT DEVE VO_L_Y
K
C
M
Y
:
A㧦 0
㧧 (0:YES 1:NO)
SIMULATION
NO.26
㧙
01
ESCAPE TRAY SETUP
0
㨇 0㨪 1 㨉
OK
TEST
CLOSE
