MX-2300/2700 N/G SIMULATION 7 – 68
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
4) Enter the set value with 10-key.
* When [C] key is pressed, the input value is cleared.
* The set values can be collectively changed by pressing [V]
[U] buttons.
When the set value is not the upper limit value (lower limit
value), the data of each item is increased (decreased) by 1.
5) When [OK], [EXECUTE], [↑], [↓], [U], [V] button, [COLOR], or
[BLACK] key is pressed, the current entered value is saved to
EEPROM and RAM.
6) When [EXECUTE] button is pressed, it is highlighted and self
print is executed.
* When [C], [CA], [SYSTEM SETTINGS], or [EXECUTE] but-
ton is pressed during self print, the operation is terminated.
* After completion of self print, [EXECUTE] button returns to
the original state.
* When [SYSTEM SETTINGS] key is pressed once during setting,
the display returns to the menu selecting screen.
* When [SYSTEM SETTINGS] key is pressed twice during setting,
the display returns to the sub number entry screen.
<Setting item>
<Set range and default value of each setup>
46-16
Purpose : Adjustment
Function (Purpose) : Used to the copy density adjustment (man-
ual) [Monochrome, all modes] PG print.
Section :Engine
Item : Operation
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
* The set values can be collectively changed by pressing [U]
[V] buttons.
When the set value is not the upper limit value (lower limit
value), the data of each item is increased (decreased) by 1.
3) When [EXECUTE] button is pressed, it is highlighted and self
print is started.
* When [OK], [EXECUTE], [↑], [↓], [U], [V] button, [COLOR],
or [BLACK] key is pressed, the data are saved to EEPROM
and RAM.
* After completion of self print, [EXECUTE] button returns to
the normal display.
<Set range and default value of each setup>
Item Item content
TEXT Text
TEXT/PRT PHOTO Text/Printed Photo
PRINTED PHOTO Printed Photo
PHOTO+TEXT/PHOTO Photo+Text/Photo
MAP Map
LIGHT Light density document
COPY ORG Copy document
Item Display Item Set range Default value
A POINT1 Point 1 245 to 755 500
B POINT2 Point 2 245 to 755 500
C POINT3 Point 3 245 to 755 500
D POINT4 Point 4 245 to 755 500
E POINT5 Point 5 245 to 755 500
F POINT6 Point 6 245 to 755 500
G POINT7 Point 7 245 to 755 500
H POINT8 Point 8 245 to 755 500
I POINT9 Point 9 245 to 755 500
J POINT10 Point 10 245 to 755 500
K POINT11 Point 11 245 to 755 500
L POINT12 Point 12 245 to 755 500
M POINT13 Point 13 245 to 755 500
N POINT14 Point 14 245 to 755 500
O POINT15 Point 15 245 to 755 500
SIMULATI ON  NO.46  10
TEST
ENGINE COLOR BALANCE MANUAL ADJUSTME NT
1/1
0
TEXT
TEXT / PRT  PHOTO
PRINTED PHOTO PHOTO+T EX T/ PHOTO
CLOSE
MAP LIGHT COPY ORG
Item Display Item Set range Default value
A POINT1 Point 1 373 to 627 500
B POINT2 Point 2 373 to 627 500
C POINT3 Point 3 373 to 627 500
D POINT4 Point 4 373 to 627 500
E POINT5 Point 5 373 to 627 500
F POINT6 Point 6 373 to 627 500
G POINT7 Point 7 373 to 627 500
H POINT8 Point 8 373 to 627 500
I POINT9 Point 9 373 to 627 500
J POINT10 Point 10 373 to 627 500
K POINT11 Point 11 373 to 627 500
L POINT12 Point 12 373 to 627 500
M POINT13 Point 13 373 to 627 500
N POINT14 Point 14 373 to 627 500
O POINT15 Point 15 373 to 627 500
A
:
A㧦500
B㧦500
C㧦500
D㧦500
㧧 POINT1
㧧 POINT2
㧧 POINT3
㧧 POINT4
SIMULATION  NO.46 㧙 16
ENGINE COLOR BALANCE MANUAL ADJUSTMENT [ALL(B/W)]:PG
500
㨇373㨪627㨉
OK
TEST
0
EXECUTE
CLOSE
