MX-2300/2700 N/G SIMULATION 7 – 69
46-19
Purpose : Setting
Function (Purpose) : Used to set the BLACK auto exposure
mode.
Section : Scanner
Item : Operation
Operation/Procedure
1) When the machine enters the simulation, the current set status
is highlighted.
2) Press a set value button to be changed, and the button is high-
lighted and the set value is saved to EEPROM and RAM. (In
this example, [MODE2] button is pressed.)
* Only one item can be selected.
* When [CLOSE] button is pressed, the display is shifted to the
copy basic screen of simulation.
* Copying can be performed also by pressing [COLOR]/[BLACK]
key.
<Set range and default value of each set value>
46-21
Purpose : Adjustment
Function (Purpose) : Used to perform the copy color balance
manual correction.
[Color, All modes]: PG print
Section : Engine
Item : Adjustment
Operation/Procedure
1) Select a color with [K][C][M][Y] buttons. The adjustment value
of the selected color is displayed. (In this example, [C] is
selected.)
* Only one color button can be selected. The selected button
is highlighted. (On the default display, [K] is selected.)
* Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
* The set values can be collectively changed by pressing [V]
[U] buttons.
When the set value is not the upper limit value (lower limit
value), the data of each item is increased (decreased) by 1.
3) When [EXECUTE] button is pressed, it is highlighted, and self
print is started.
* When [OK], [EXECUTE], [↑], [↓], [U], [V] button, [COLOR],
or [BLACK] key is pressed, the data are saved to EEPROM
and RAM.
* After completion of self print, [EXECUTE] button returns to
the normal display.
* When [C], [CA], [SYSTEM SETTINGS], or [EXECUTE] key
is pressed during self-printing, the operation is stopped.
<Set range and default value of each setup>
46-23
Purpose :Setting
Function (Purpose) : Used to set ENABLE/DISABLE of the half
tone highest density correction.
Section :
Item : Specifications
Operation/Procedure
1) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
2) When [OK] button, [COLOR] or [BLACK] key is pressed, the
current entered value is saved to EEPROM and RAM.
<Set range and default value of each setup>
Item Content Set value
Default
value
AE_MODE Auto exposure mode MODE1,
MODE2
MODE1
AE_STOP_COPY Auto BLACK exposure STOP
(for copy)
ON/OFF ON
AE_STOP_FAX Auto BLACK exposure STOP
(for FAX)
ON/OFF ON
AE_STOP_SCAN Auto BLACK exposure STOP
(for scanner)
ON/OFF ON
CLOSE
0
MODE1
ON
SIMULATION NO.46-19
TEST
EXPOSURE MODE SETUP (B/W-AE)
1/1
AE MODE :
MODE2
OFF
ON
AE STOP COPY :
AE STOP FAX :
AE STOP SCAN :
OFF
ON
OFF
Item Display Item Set range Default value
A POINT1 Point 1 245 to 755 500
B POINT2 Point 2 245 to 755 500
C POINT3 Point 3 245 to 755 500
D POINT4 Point 4 245 to 755 500
E POINT5 Point 5 245 to 755 500
F POINT6 Point 6 245 to 755 500
G POINT7 Point 7 245 to 755 500
H POINT8 Point 8 245 to 755 500
I POINT9 Point 9 245 to 755 500
J POINT10 Point 10 245 to 755 500
K POINT11 Point 11 245 to 755 500
L POINT12 Point 12 245 to 755 500
M POINT13 Point 13 245 to 755 500
N POINT14 Point 14 245 to 755 500
O POINT15 Point 15 245 to 755 500
Item Display Content
Set
range
Default
value
A (0: ENABLE
1: DISABLE)
0 Engine highest density
correction mode ENABLE
0 to 1 0
1 Engine highest density
correction mode DISABLE
:
A㧦500
B㧦500
C㧦500
㧧 POINT1
㧧 POINT2
㧧 POINT3
SIMULATION
NO.46
㧙
21
ENGINE COLOR BALANCE MANUAL ADJUSTMENT [ALL(COLOR)]
500
㨇245~755㨉
OK
TEST
K
C
M
Y
CLOSE
EXECUTE
D:500
㧧 POINT4
To Next Page
