MX-2300/2700 N/G SIMULATION 7 – 73
ORG RECOG
(Document type
auto recognition)
RESULT
(Judgment result)
ORIGINAL TXT Document Auto text 1
TXT/HT Auto text mesh 2
HT Auto mesh 3
TXT/PIC Auto text/photo 4
PIC Auto photo 5
TXT ON HT Auto text on dot 6
OHT Other auto 7
BACKGROUND – Base None 1
GR Gray 2
WH White 3
NE Newspaper 4
WH_GR White gray 5
WH_NE White newspaper 6
WH_CO White color 7
CO Color 8
IM Image 9
MESH – Mesh No mesh 0
IMAGE Image mesh 1
BASE Base mesh (Non-image
mesh)
2
HTFE HIGH Line High number of lines 1
LOW Low number of lines 0
STATISTICS
(Image process
statistic amount)
HTCNT Mesh counter value Max. 10 digits A3 pixel number
PHOTOCNT Photographic paper counter value Max. 10 digits A3 pixel number
STRCNT Text counter value Max. 10 digits A3 pixel number
FLATCNT Background counter value Max. 10 digits A3 pixel number
PREHTCNT Document type judgment mesh counter
value
Max. 10 digits A3 pixel number
HTXTCNT Text on mesh counter value Max. 10 digits A3 pixel number
SUMF Flat mesh counter value Max. 10 digits
SUMM_L Total of Max. reverse numbers (lower
32bit)
Max. 10 digits
SUMM_H Total of Max. reverse numbers (Upper
4bit)
Max. 3 digits
SUMFM_L Total of flat section max. reverse
number (lower 32bit)
Max. 10 digits
SUMFM_H Total of flat section max. reverse
number (Upper 4bit)
Max. 3 digits
FHSTDR Background pixel histogram value
(RED)
Max. 10 digits #1 to #32 display A3
pixel number
FHSTDG Background pixel histogram value
(GREEN)
Max. 10 digits
FHSTDB Background pixel histogram value
(BLUE)
Max. 10 digits
HTHSTDR Mesh pixel histogram value (RED) Max. 10 digits
Category Detail of category Display Content
Set range/
Number of
digits
Remark
