Shimadzu LC-10/20 System 3 Installation Procedure
Fig 7: Hardware Configuration
Pumps
Sets the model of the pump connected. Up to three pumps may be
configured in a Shimadzu LC-10 and four pumps on Shimadzu LC-20
System.
The first pump may have valves configured, other pumps are not allowed
to have any valves. Any pump may be set as gradient or auxiliary, but
maximum of four solvents can be used in a gradient, so any further pumps
are automatically configured as auxiliary.
Detectors
Sets the model of the detector connected. Up to two detectors may be
configured in a Shimadzu LC-10/20 System.
Autosampler
Sets the model of the autosampler.
PDA Detector
Set the model of the PDA detector.
Thermostat
Sets the model of the thermostat.
Note: It is recommended to add the modules one by one and to check the
communication with the Connect button in between.
- 13 -
