Shimadzu LC-10/20 System 6 Vial Plate Numbers
6 Vial Plate Numbers
The following tables show the Vial Number mapping on the various trays
used with Shimadzu LC-10/20 System autosamplers:
Tab 6: Vial numbers on vial trays:
Rack type Subtype or model Vial numbers
1, 11 0 - 149
2, 12, 12A 0 - 69
3, 13 0 - 59
4, 4U, 14, 14A, 14DDW
Single 1 - 96
Dual 1 - 192
5, 5U, 15
Single 1 - 384
Dual 1 - 768
6, 16 0 - 99
7 0 - 69
S 0 - 99
S Peltier 0 - 59
L 0 - 79
L Peltier 0 - 49
LL 0 - 24
MTP Dual 1 - 192
1.5ml Standard
SIL-HTA, SIL-HTC 1001 - 1105, 2001 - 2105
Other 1 - 105
1.5ml Cooled
SIL-HTA, SIL-HTC 1001 - 1070, 2001 - 2070
Other 1 - 70
1ml Standard, 1ml Cooled
SIL-HTA, SIL-HTC 1007 - 1175, 2001 - 2175
Other 1 - 175
4ml Standard, 4ml Cooled
SIL-HTA, SIL-HTC 1001 - 1050, 2001 - 2050
Other 1 - 50
MTP96 Standard, MTP96
Cooled, DW96 Standard,
DW96 Cooled
SIL-HTA, SIL-HTC
1001 - 1096, 2001 - 2096,
3001 - 3096, 4001 - 4096
Other 1001 - 1096, 2001 - 2096
MTP384 Standard,
MTP384 Cooled
SIL-HTA, SIL-HTC
1001 - 1384, 2001 - 2384,
3001 - 3384, 4001 - 4384
Other 1001 - 1384, 2001 - 2384
With a Rackchanger (device usable with the SIL-20 autosamplers) the
vial number mapping changes a bit: A Rackchanger has four holders,
each with three trays. All vial trays in a single holder must be the same,
but can differ between different holders. The vial's numbering is performed
- 71 -
