4 Using the control module Clarity Controls
4.1.3 Method Setup - LC
If the only pump was set to Auxiliary mode in the Shimadzu LC-10/20
System Setup - Pump dialog, the LC tab will appear instead of the LC
Gradient tab. The LC tab will also appear if the second pump is set to
Auxiliary mode (showing only the Auxiliary Pump sub- tab) or when
primary pump is configured with valve and only one solvent in the
Shimadzu LC-10/20 System Setup - Pump dialog (showing only the LC
Valve sub-tab).
In case that several pumps with the LC tab available are configured on the
same Clarity Instrument, it is possible to switch between them using the
Select LC menu on the top of the LC tab.
From LC
Acquires the status of the auxiliary pump from the controller.
LC Status
Invokes the hardware configuration dialog listing the settings of the
Shimadzu LC-10/20 System. The upper part shows the settings of the
controller, the lower part the settings of other modules.
Fig 12: Method Setup - LC - Hardware Configuration
- 23 -
