Shimadzu LC-10/20 System 4 Using the control module
4.5.4 Device Monitor
The Device Monitor window can be invoked by the Monitor - Device
Monitor command from the Instrument window or using the Device
Monitor icon. Thermostat Device Monitor serves for monitoring the
actual thermostat temperature and allows to switch the thermostat on and
off. The room temperature is also displayed.
Fig 52: Device Monitor - Thermostat
Switch Therm. On (Off)
Toggles the thermostat program (as set on the Method Setup - Thermostat
tab) on and off.
Actual Temperature
Field displaying the actual thermostat temperature.
Room Temperature
Field displaying the actual room temperature.
- 68 -
