SICK Flexi Classic series User Manual

Operating instructions Chapter 11
Flexi Classic
8011509/YPP0/2015-10-26 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 103
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Load capacity – – 500 nF
Cable length (single, Ø 1.5 mm²) – – 100 m
Local response time cut-off path
(I1/I2)
23)
– – 29 ms
Local response time cut-off path
(I3/I4)
23)
program 2, 3, 4 and 5
– – 29 ms
Local response time cut-off path
(I3/I4)
23)
program 6, 7
– – 13 ms
Local response time cut-off path
(I4)
23)
program 8, 9 with tested
electro-sensitive protective device
cat. 4 (e.g. L41)
– – 56 ms
Local response time
24)
on
connection of Flexi Loop
– – 56 ms
Global emergency stop circuit (O
P
-I
N
, O
N
-I
P
)
Cable length O
X
to I
X
– – 100 m
Cable length all stations, global
emergency stop function
25)
– – 1000 m
Number of stations, global
emergency stop function
– – 32
Global response time I
X
to O
X
– – 40 ms
Global power-up delay I
X
– 80 ms 120 ms
General system data
Weight (without packaging) – 0.18 kg –
Electrical safety Class III
Interference resistance EN 61 000-6-2
Radiated emission EN 61 000-6-4
Operating data
Ambient operating temperature
(UL/CSA: ambient temperature)
–25 °C – 55 °C
Storage temperature –25 °C – 70 °C
Air humidity 10 % to 95 %, non-dewing
Climatic conditions EN 61 131-2
Mechanical strength
Vibration EN 61 131-2
Vibration resistance 5-500 Hz/5 grms (EN 60 068-2-64)
23)
Time without sensor, in addition the data for the sensors connected apply.
24)
Response time not including Flexi Loop and not including sensor. Also take into account the response times of
Flexi Loop and the sensors connected.
25)
The input voltage levels (I1-I6, I
P
,I
N
) must be met.
