Operating instructions Chapter 11
Flexi Classic
8011509/YPP0/2015-10-26 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 99
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Response time (EN)
18)
– – 13 ms
0 / 0.5 / 1 /1.5 / 2 / 2.5 / 3 / 3.5 / 4 / 5 s
0 / 5 / 10 / 15 / 20 / 25 / 30 / 35 / 40 / 50 s
Time delay (adjustable)
0 / 0.5 / 1 / 1.5 / 2 / 2.5 / 3 / 3.5 / 4 / 5 min
General system data
Weight (without packaging) – 0.18 kg –
Electrical safety Class III
Interference resistance EN 61 000-6-2
Radiated emission EN 61 000-6-4
Operating data
Ambient operating temperature
(UL/CSA: ambient temperature)
–25 °C – 55 °C
Storage temperature –25 °C – 70 °C
Air humidity 10 % to 95 %, non-condensing
Climatic conditions EN 61 131-2
Mechanical strength
Vibration EN 61 131-2
Vibration resistance 5-500 Hz/5 grms (EN 60 068-2-64)
Terminal and connection data
Single-wire or fine-wire
1 × 0.14 mm² to 2.5 mm² or
2 × 0.14 mm² to 0.75 mm²
Fine-wire with terminal crimps to
EN 46 228
1 × 0.25 mm² to 2.5 mm² or
2 × 0.25 mm² to 0.5 mm²
Insulation stripping length – – 8 mm
Maximum tightening torque – – 0.6 Nm
For UL 508 and CSA applications
UE410-xx3…, UE410-xxx3…
– Connection cross-section AWG 30-12
(only use 60/75 °C copper flexible wire)
– Tightening torque
5-7 lb⋅in
UE410-xx4…, UE410-xxx4…
– Connection cross-section AWG 30-12
(only use 60/75 °C copper flexible wire)
18)
Cascading subsystems.
