122 FLOWSIC600-XT · Operating Instructions · 8018846/1BHP/V2-1/2021-05 · © SICK Engineering GmbH
Specifications
Subject to change without notice
Conformities and Approvals
Conformities OIML R137 1&2-2012
OIML D11-2013
ISO 17089-1
AGA Report No. 9
MID 2014/32/EU
PED 2014/68/EU
ATEX 2014/34/EU
EMC 2014/30/EU
GOST 8.611-2013
GOST 8.733-2011
Ex Approvals IECEx Ex db ia op is [ia Ga] IIA /IIC T4 Gb
Ex db eb ia op is [ia Ga] IIA/IIC T4 Gb
Ex ia op is IIA/IIC T4 Ga
Ex nA ia op is IIC T4 Gc
ATEX II 2 (1) G Ex db ia op is [ia Ga] IIA /IIC T4 Gb
II 2 (1) G Ex db eb ia op is [ia Ga] IIA/IIC T4 Gb
II 1G Ex ia op is IIA/IIC T4 Ga
II 3G Ex nA ia op is IIC T4 Gc
NEC/CEC (US/CA) Explosion-proof/non-flammable:
CI I, Div. 1 Group D, T4 / Ex d ia [ia Ga] IIA T4 Gb / Cl I, Zone 1 AEx d
ia op is [ia Ga] IIA T4 Gb
Cl I, Div. 2 Groups A, B, C, D, T4 /Ex ia nA IIC T4 Gc / Cl I Zone 2, AEx
ia nA op is IIC T4 Gc
CI I, Div. 1 Groups B, C, D, T4 / Ex d ia [ia Ga] IIC T4 Gb / Cl I, Zone 1
AEx d ia op is [ia Ga] IIC T4 Gb
CI I, Div. 2 Groups A, B, C, D, T4 / Ex ia nA IIC T4 Gc / Cl I, Zone 2, AEx
ia nA op is IIC T4 Gc
Intrinsically safe:
CI I, Div. 1 Group D T4 / Ex ia IIA T4 Ga / Cl I, Zone 0, AEx ia op is IIA
T4 Ga
CI I, Div. 1 Groups A, B, C, D, T4 / Ex ia IIC T4 Ga / Cl I, Zone 0, AEx ia
op is IIC T4 Ga
Non-flammable:
Cl I, Div. 2, Groups A, B, C, D, T4 / Ex ia nA IIC T4 Gc / Cl I Zone 2, AEx
ia nA op is IIC T4 Gc
IP classification IP66 according to ATEX/IECEx/CSA approval
IP67 according to IEC60529, with additional Certificate
Outputs and interfaces
Analog outputs 1 output:
4 … 20 mA, max. 250 Ω
Active/passive, electrically isolated
Digital outputs 4 outputs:
≤ 30 V, 50 mA
Passive, electrically isolated, Open Collector or in accordance with NAMUR (DIN EN 60947-5-6),
f
max
= 10 kHz
Interfaces Optical Service interface (IR, in accordance with IEC 62056-21)
RS-485 (3x)
Ethernet TCP (1x optional)
HART-Master (external pressure and temperature transmitter)
Encoder
Bus protocol Modbus ASCII
Modbus RTU
Modbus TCP (optional)
Register assignments (optional):
DSFG, instance F / ISO 17089
FLOWSIC600-compatible Modbus registers
Operation Via meter display (read access) and the FLOWgate
TM
operating software
