SICK FLOWSIC600-XT User Manual

Specifications
FLOWSIC600-XT · Operating Instructions · 8018846/1BHP/V2-1/2021-05 · © SICK Engineering GmbH 129
Subject to change without notice
26" cl. 150 ASME
B16.47
1475 1050 965 870 828 585
cl. 300 1825 1016 972
cl. 600 2100 1038 1016
cl. 900 2500 1250 1073 1086
DN650 Data on request
28" cl. 150 ASME
B16.47
1950 1100 1027 927 862 630
cl. 300 2225 1080 1035
cl. 600 2450 1100 1073
cl. 900 3000 1300 1150 1169
DN700 Data on request
30" cl. 150 ASME
B16.47
2195 1150 1080 985 902 675
cl. 300 2545 1135 1092
cl. 600 2820 1154 1130
cl. 900 3350 1350 1205 1232
DN750 Data on request
32" cl. 150 ASME
B16.47
2485 1200 1145 1061 979 720
cl. 300 2835 1190 1150
cl. 600 3110 1212 1194
cl. 900 3800 1400 1272 1315
DN800 Data on request
34" Data on request
DN850
36" cl. 150 ASME
B16.47
3125 1250 1250 1169 1082 810
cl. 300 3525 1300 1270
cl. 600 3850 1323 1315
cl. 900 5225 1450 1396 1461
DN900 Data on request
38" cl. 150 ASME
B16.47
3800 1300 1310 1238 1160 855
cl. 300 3725 1275 1169
cl. 600 4300 1325 1270
cl. 900 Data on request 1421 1461
DN950 Data on request
40" cl. 150 ASME
B16.47
3825 1350 1359 1289 1213 900
cl. 300 4125 1334 1239
cl. 600 4675 1375 1321
cl. 900 Data on request 1470 1512
DN1000 Data on request
42" cl. 150 ASME
B16.47
4675 1450 1415 1346 1261 945
cl. 300 4650 1386 1289
cl. 600 5450 1444 1404
cl. 900 Data on request 1523 1562
DN1050 PN 16 Data on request
44" Data on request
DN1100
46" Data on request
DN1150
Nominal
pipe size
Connection
flange
Standard
Weight
[1]
Length (A)
Height
[2]
(B)
Flange
diameter
(C)
Outer
diameter,
meter body
(D)
Inner
diameter
(E)
[kg] [mm] [mm] [mm] [mm] [mm]
