8017171/115Z/V3-0/2019-01| SICKO P E R A T I N G I N S T R U C T I O N S | VISIC100SF
Subject to change without notice
INSTALLATION
3.5 VISIC100SF wiring
3.5.1 Electrical installation safety information
WARNING: Hazard by voltage.
▸ Only allow an authorized electrician to work on the electric system.
▸ Observe the relevant safety regulations during all installation work.
▸ Take suitable protective measures against local risks and those arising from the
plant.
NOTE: Onsite electrical installation is the responsibility of the operator.
Provide separate external main power switches which disconnect all
connectors, and fuses in the proximity of the VISIC100SF (max. power input of
the VISIC100SF
→ Technical data)
NOTE: Device damage through electrostatic discharges
The VISIC100SF may be connected only by an expert.
▸ Observe the applicable ESD Guidelines.
NOTE: Avoid damage to the electronics
Before signal connections are established (also with plug connections):
▸ Separate the VISIC100SF, the terminal box and/or TAD control unit from the main
power supply.
The terminal box and/or the TAD control unit do not have independent main power
switches. In accordance with EN 61010, the following must be ensured before
installation:
● A main power switch is available in the tunnel.
● Service personnel can easily access the main power switch.
● The main power switch is marked as disconnecting device.
