INSTALLATION
3.4 Assembly
3.4.1 Scope of delivery
▸ Check the scope of delivery against the order and delivery documents.
3.4.2 Installing the VISIC100SF
1 Determine the sensor installation location according to the project planning.
Fig. 13: Maximum allowable angle of inclination and installation location height
Fig. 14: Maximum allowable angle of inclination of fitted VISIC100SF
Max. 45 °
Depending on the
* SICK recommends installation above the
splash water area.
Use a wall plate when the installation walls are extremely uneven. Consider this special
solution during project planning.
