VISIC100SF MENU NAVIGATION
5.5.4 Setting the Modbus baud rate with menu item “MB BdR”
Submenu item “MB BdR” serves to set the Modbus interface baud rate:
● 4.8 k
● 9.6 k
● 19.2 k
● 38.4 k
● 57.6 k
Fig. 43: Setting the Modbus interface baud rate
RUN
X
XXX
Set
SET
Maint
Esc
Set
>
>
SET
MB ID
Esc
Set
2 s
4800B
>
>
... ...
SET
Bus
Set
Esc
>
>
MB BdR
9600B
>
>
Set
19200B
Set
38400B
>
>
Set
>
>
57600B
>
>
Set
SET
SET
SET
SET
SET
SET
All “Bus” settings are first saved after a VISIC100SF restart.
