42
8017171/115Z/V3-0/2019-01| SICKO P E R A T I N G I N S T R U C T I O N S | VISIC100SF
Subject to change without notice
INSTALLATION
3.7.4.2 PROFIBUS DP-V0 baud rates
The PROFIBUS module has an autobaud function that automatically detects the following
baud rates:
● 9.6 k
● 19.2 k
● 45.45 k
● 93.75 k
● 187.5 k
● 500 k
● 1.5 M
3.7.4.3 Access via GSD file
The GSD file provided allows access to the following modules on the PROFIBUS master:
Table 12: GSD file modules
Module (coding) Significance
KValue (Real), Status (UInt8) Visibility measured value
DustValue (Real),Status (UInt8) Dust concentration
Uptime VISIC100SF [h]
(UInt16)
Operating duration of VISIC100SF since last reset in hours
OpHours VISIC100SF [d]
(UInt16)
Total operating duration of VISIC100SF in days
CoValue (Real), Status (UInt8) CO gas concentration in ppm
NxtMrq CO-Cell [d] (UInt16) Operating days until next maintenance request of CO cell
OpHours CO-Cell [d] (UInt16) Operating duration of CO cell in days
NoValue (Real), Status (UInt8) NO gas concentration in ppm
NxtMrq NO-Cell [d] (UInt16) Operating days until next maintenance request of NO cell
OpHours NO-Cell [d] (UInt16) Operating duration of NO cell in days
NO
2
Value (Real), Status (UInt8) NO
2
gas concentration in ppm
NxtMrq NO
2
-Cell [d] (UInt16) Operating days until next maintenance request of NO
2
cell
OpHours NO
2
-Cell [d] (UInt16) Operating duration of NO
2
cell in days
Contamination (UInt16) Contamination of sensor in percent
Temperature (Real), Status
(UInt8)
Temperature of external PT1000 in °C
MainReq (UInt16)
Maintenance request, coded bit-by-bit, compare “Description of
maintenance requests”, page 96
DeviceFault (UInt16) Error status byte, compare “Device error coding”, page 95
Counter (UInt16) Measured value meter
CRC16-CCITT (UInt16) Checksum according to CRC16-CCITT
The GSD file is delivered on a CD when the PROFIBUS module is ordered. It is also
available as download on SICK's homepage.
