SIEB & MEYER SD2 Series User Manual

Specification of Drive Functions
Drive function SERVO / VECTOR VF
SVC:
▸
Synchronous rotative
▸
Up to 2000 Hz rotating field frequency
Software
Drive function SERVO / VECTOR VF
Software pack-
ages
(1)
L01002Vxxxxx & F01001Vxxxxx
▸
special function: EnDat 2.1
L01004Vxxxxx & F01004Vxxxxx
L01003Vxxxxx & F01003Vxxxxx
▸
special function: Hiperface
L01007Vxxxxx & F01006Vxxxxx
▸
special function: electronic gear
L01002Vxxxxx & F01009Vxxxxx
▸
special function: SVC
(1)
After the firmware and logic software have been detected, the SD2 software packages can be identified
by the number '1' contained in the software designation (e.g. logic software = Lx1xxx, firmware = Fx1xxx).
Measuring system
Drive function SERVO / VECTOR VF
Measuring systems L01002 / F01001
▸
Resolver (up to 666 Hz)
▸
Incremental encoder TTL with
magnetic alignment (5 V / max.
2.5 MHz
(1)
)
▸
Sine/cosine encoder with magnetic
alignment (1 V
pp
/ max. 230 kHz
(1)
)
▸
Sine/cosine encoder with EnDat 2.1
(1 V
pp
/ max. 230 kHz
(1)
)
▸
Linear Hall encoder
L01004 / F01004
▸
Sensorless
▸
Field plate 3-wire
L01003 / F01003
▸
Resolver (up to 666 Hz)
▸
Incremental encoder TTL with
magnetic alignment (5 V / max.
2.5 MHz
(1)
)
▸
Sine/cosine encoder with magnetic
alignment (1 V
pp
/ max. 230 kHz
(1)
)
▸
Sine/cosine encoder with Hiperface
(1 V
pp
/ max. 230 kHz
(1)
)
▸
Linear Hall encoder
L01007 / F01006
▸
Resolver (up to 666 Hz)
▸
Incremental encoder TTL with
magnetic alignment (5 V / max.
2.5 MHz
(1)
)
▸
Sine/cosine encoder with magnetic
alignment (1 V
pp
/ max. 230 kHz
(1)
)
▸
Linear Hall encoder
L01002 / F01009
▸
Sensorless Vector Control (SVC)
(1)
This specification applies per track.
182 Drive System SD2 - Hardware Description
