Siemens CP-8000

System Components and Technical Data
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 127
DC8-037-2.02, Edition 10.2017
Note
Details about realization of various operation modes are given in the manual SICAM RTUs Platforms -
Configuration Automation Units and Automation Networks.
5.5.9.3 Communication
For the communication infrastructure, additional suitable transmission facilities and/or network
components may be needed.
Own Station (Central Station)
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
DNPMT0
Remote Station (Substation)
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
DNPST0
SICAM AK 3 CP-2016/CPCX26
CP-2019/PCCX26
SM-2551/DNPSA0
SM-0551/DNPSA0
Legacy systems
(SICAM AK,
SICAM TM,
SICAM BC, Ax 1703)
CP-20xx
CP-50xx
CP-60xx
SM-2551/DNPSA0
SM-0551/DNPSA0
SM-2541/DNPU00
acc. to SICAM RTUs DNP3
Interoperability
Third-party system – – acc. to SICAM RTUs DNP3
Interoperability
Own Station (Substation)
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
DNPST0
Remote Station (Central Station)
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
DNPMT0
SICAM AK 3 CP-2016/CPCX26
CP-2019/PCCX26
SM-2551/DNPMA0
SM-0551/DNPMA0
Legacy systems
(SICAM AK,
SICAM TM,
SICAM BC, Ax 1703)
CP-20xx
CP-50xx
CP-60xx
SM-2551/DNPMA0
SM-0551/DNPMA0
SM-2541/DNPM00
SM-1543/DNPM00
acc. to SICAM RTUs DNP3
Interoperability
Third-party system – – acc. to SICAM RTUs DNP3
Interoperability
