Siemens CP-8000

Installation and Circuitry
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 177
DC8-037-2.02, Edition 10.2017
6.4.1.2 Space Requirement with SICAM TM I/O Modules
If the device is extended by external SICAM TM I/O Modules (max. 6 are permitted), then you
must consider the width of the coupling module, the I/O Modules, the bus protection cap and
the end clamp.
Example: CP-8000 + 6 ext. SICAM TM I/O Modules
Thermical space ..................................................... 30
CP-8000................................................................128
CM-6811 coupling module ........................................ 5
6 SICAM TM I/O Modules (6 x 63) ..........................378
Protective cap for bus ............................................... 3
End clamp ................................................................ 5
Horizontal space requirement (mm)........................549
m
i
n
.
30 *)
12830
124
30
5
SICAM CMIC
F4F3F2F1
P OK
RY
ER
ETH
L K1
P K1
RS-2 32
OH2
RTX2
RS-4 85
OH3
RTX3
ETH
L K4
P K4
SD
X4
63 63 63 63
549
53
SICAM A8000 CP- 8000
63 63
