Siemens CP-8000

Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 387
DC8-037-2.02, Edition 10.2017
Processing type Parameter Meaning
RS_Image_IOA2 Address of corresponding return state infor-
mation (S)
0 to 255
RS_Image_IOA3 Address of corresponding return state infor-
mation (S)
0 to 255
Term_with_Conf Sending of termination immediately after
sending of confirmation (S)
NO/YES
Output_t Command output time in seconds (S).
Attention: The time comes into effect only, if in
the message is not defined any time.
0.01 to 327.67
termination_t Time between confirmation and termination (s)
0 = no termination
0 to 6553.5
RS_react_t Information reaction time (S)
Pulse command: 0 .. time appropriate to
output time
Persisitent command: 0 .. time appropriate to
termination time
0 to 6553.5
SW_CO_SYNC_A –
command synchroniza-
tion abortion
–
SW_CO_SYNC_R -
command synchroniza-
tion is running
–
SW_DO – Software data
point digital output
–
9.1.11.4.4 Parameters with Assignment on the AI Module
Processing type Parameter Meaning
AI_I – current value
acqisition
line frequency The noise rejection takes place for the
parametrized line frequency
• 50 Hz
• 60 Hz
• 16.7 Hz
Zero range Zero range suppression (and check of the
plausibility limits) (S)
NO/YES
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
thresh_uncond Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 103.00
block Blocking (=not used) (S)
NO/YES
