Installation and Circuitry
174 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
6.3.2 Cable Duct
Cable ducts are recommended for the cabling above and below the device. The minimum dis-
tance from the device to the cable duct is 30 mm.
Note
When using a cable duct with 100 mm depth below the device, it is necessary to keep a 50 mm minimum
distance between device and cable duct to operate the locking hook.
