Service
484 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
11.1.2.3.3 Version
In the submenu Version the version numbers of
the individual firmwares are displayed.
11.1.2.4 Monitoring
The menu item Monitoring is devided in the
submenus
• Events
• Alarms
• Cockpit
• I/O Modules
The submenu Events | ALL Events displays a list with max. of 4000 process and diagnosis
events.
The submenu Alarms displays a list with max. of 4000 process and diagnosis alarms (you
may also view the alarm list from the main menu item Alarms).
The submenu Cockpit displays up to 32 configurable groups with up to 255 signals each.
The submenu I/O Modules displays the signal states at the inputs and outputs of the
equipped I/O Modules.
