Siemens CP-8000

Installation and Circuitry
232 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
6.11.1.5.2 CP-802x
Wiring for Modem Cable
Connection CTS–GND: see note at page 212.
CP-8021
CP-8022
8 to 30 VDC
Cinterion MC52iT or
MC55iw Terminal
GND
RXD
RI
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
DSR
CTS
RTS
DCD
DTR
TXD
MC52iT
MC55iw
GND
V+
IGT_IN
PD_IN
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
CTS
RTS
VCC
TXD
RXD
GND
DCD
DTR
1
2
3
4
5
6
7
8
6-pole
RJ12
Shield
Shield
Shield
DC DC
8 V to 30 V
8-pole RJ45
male
