5.2 Mechanical Design
CP-8000 CP-8021 CP-8022
Mechanics
Structure System for mounting on
35 mm DIN rail
System for mounting on
35 mm DIN rail
System for mounting on
35 mm DIN rail
Dimension (HxWxD) 124 x 128 x 123 mm 132 x 30 x 142 mm 132 x 30 x 142 mm
Weight ca. 800 g ca. 210 g ca. 260 g
Connections
Connection system
for peripheral signals
and power supply
Removeable screw
terminals, wire cross
section up to 2.5 mm²
(applies for wires with
realization rigid/multi-
wire/fine-wire with con-
ductor end sleeve)
– –
Ethernet/LAN Com-
munication via
2x RJ45 socket connect-
or 8-pole, for connecting
cat.5 cable
X1, X4
2x RJ45 socket connect-
or 8-pole, for connecting
cat.5 cable
X1, X4
2x RJ45 socket connect-
or 8-pole, for connecting
cat.5 cable
X1, X4
Communication via
RS-232
D-SUB 9-pole, male,
with additional supply
output for external
transmission facility
X2
1x RJ45 socket 8-pole,
with supply output for
external transmission
facility
X2
1x RJ45 socket 8-pole,
with supply output for
external transmission
facility
X2
1x removable push-in
terminal 8-pole
X6
1)
Communication via
RS-485 (RS-422)
1x removable screw
terminal 6-pole
X3
1x removable push-in
terminal 8-pole
X3
2x removable push-in
terminal 8-pole
X3, X6
1)
Peripheral bus 5-pole connector for
SICAM I/O coupling
module or
SICAM TM I/O coupling
module
18-pole connector for
bus connector
18-pole connector for
bus connector
Communication via
GPRS
2) 2)
SMA connector
X7
1)
interface can be used optionally for RS-232 or RS-485 communication
2)
ext. GPRS modem/router with Ethernet/LAN interface
