Siemens CP-8000

Installation and Circuitry
214 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
6.11.1.1.2 CP-802x
Wiring for Modem Cable
Connection CTS–GND: see note at page 212.
V.24/V.28 (X1)
CE-070x
CP-8021
CP-8022
RS-232 (X2)
Cable
max. 330 mm
CP-802x
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
GND
+5 V
1
2
3
4
5
6
7
8
X1:1
X1:2
X1:3
X1:4
X1:5
X1:6
X1:7
X1:8
1
2
3
4
5
6
7
8
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
X2:9
1
2
3
4
5
6
7
8
9
DCD (O)
TXD (I)
DTR
GND
RXD (O)
RTS (I)
CTS
n.c.
CTS
RTS
VCC/5 V
TXD
RXD
GND
DCD
DTR
Shield
Shield Shield
8-pole RJ45
male
