System Components and Technical Data
144 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
5.7.1.1.2 Technical Data
Binary inputs
12 binary inputs
• 2 groups (with 8 and with 4 inputs)
• Via optocouplers the inputs are galvanical insulated from logi-
cal circuits and ground with double insulation.
• Each group is galvanically insulated from the other group,
from logical circuits and from ground with double insulation
• For each group one common return with selectable polarity
• Function and status of the inputs via display
Filter time 1 dedicated input per group 2 ms
All other inputs 3 ms
Nominal voltages 24/48/60 VDC
Operating points Logical 0 ≤ 12 V
Logical 1 ≥ 18 V
Dynamic suppression of noise
caused by cable capacitance
typ. 220 nF (for 18…78 VDC)
Rated current 0.6…1.5 mA (at 18…78 V)
Input circuits 18…78 VDC (operated by means of an external voltage)
Rated impulse voltage 4 kV
Connectors
Terminals Removable screw terminals (grid size 5.08)
