Siemens CP-8000

Installation and Circuitry
204 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
6.9.2 CP-802x
6.9.2.1 Power Supply Modules PS-8620 and PS-8622
X1
X99
PS-862x
2 3 4
1
BUS
5 V
28 V
PIC
+
-
PS-8620: DC 24...60 V
PS-8622: DC 110...220 V
galvanical
insulation
