Installation and Circuitry
216 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
Wiring for Connection CP-8000 – CM-0847 Fiberoptic Interface
Connection CTS–GND: see note at page 212.
Wiring for Connection CP-8000 – CM-0827 Fiberoptic Interface (Existing Plants)
Recommended D-Sub/RJ45 Adapter
RS Pro MHDA9-SMJ8-M-K (see appendix A.8.1, Recommended Third-Party Products). This
adapter provides a wired RJ45 socket and an unwired D-sub plug (female).
Wiring of the RJ45 socket: Wiring at the 9-pole D-sub plug:
Pin Wire color
1 black The assignment of the pins at the D-sub plug can be
made according to wiring diagram.
Not used wires must be isolated!
With use of the shield this must be soldered at the metal
plate of the D-sub plug.
2 yellow
3 orange
4 red
5 green
6 browne
7 grey
8 blue
Shield black
DCD
RXD
TXD
DTR/5 V
GND
DSR
RTS
CTS
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
X2:9
1
2
3
4
5
6
7
8
9
VCC (5 V)
RXD
TXD
GND
1
2
3
4
5
6
7
n.c.
1
2
3
4
5
6
7
8
8-pol. RJ45
männl.
8-pole RJ45
male
Shield
Shield
9-pole D-sub
female
.
RJ45 socket
D-sub plug (backside)
solding point
