Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 447
DC8-037-2.02, Edition 10.2017
Example: Analog value
When selecting a signal with datatype DINT, the value range -32768 to 32767 is dis-
played.
If you enter a valid value, for instance 10, the button is activated.
• Click on the button
The new value is written on the signal in the IL and is displayed right beside the variable type.
The test mode is automatically switched on and the button is enabled.
When entering a signal with data type REAL, you must enter the new value with a decimal
point, otherwise a corresponding notice is displayed. The display looks then as follows:
When entering the new value correctly and pressing the button , the new value is written
on the signal and is displayed right beside the data type:
If you click on the button , the test mode will be terminated.
